Shielded Ring Terminal Pass-Through Systems
HV Auxiliary Modules High Voltage Pass-Through
Bolted Pass-Through Connections
HV Auxiliary Modules
HV Power Conversion HV Power Conversion HV Power Conversion
13888001
Chargers & Charging Cables
Application
• High voltage/high vibration connections for motors or
Charging Inlets Description
power electronics
• 1 Way sealed and shielded
• Ring terminal bolted to device
• Shield bolted to device case
2
• Cable range: 25 mm to 50 mm 2
• Multiple keys/indexes
Internal Battery Connections • Current capacity: 250A at 85°C
Performance
• Voltage: 600V
• Temperature range: -40°C to +125°C
• Sealing protection: IP67, IP6K9K
HV Electrical Centers Key/ 25 mm Cable Size 35 mm Cable Size 50 mm Cable Size
Index
2
2
2
-
-
-
1
33112598
2
13888001
13888009
3
4 - 13888010 33112599
13888011
-
-
5 - - - -
HV/LV Wiring Assemblies 40 7 Part numbers, specifications, dimensions and performance data in this catalog are for general reference only and are subject to change
-
-
6
-
-
-
-
-
8
15504147
9
-
-
15504148
without notice. To verify product information, please contact a Delphi representative.
