High Voltage Auxiliary Modules
     HV Auxiliary Modules HV Auxiliary Modules  High Voltage Unshielded Connection System







            2 Way and 3 Way
  HV Auxiliary Modules


     HV Power Conversion









                                                                 13848288

     Chargers & Charging Cables












            Application                                          15530997
            •  High voltage connection internal to modules requiring
     Charging Inlets  Description
              unsealed/unshielded cable such as battery electrical centers


            •  Cavity isolation for high voltage applications
            •  Unsealed/unshielded connection system
            •  Finger proof/touch safe
            •  Cable range: 2 mm  to 5 mm  power circuit
                                     2
                             2
            •  Hinged terminal secondary lock
     Internal Battery Connections  Performance
            •  Current capacity: 40A at 85°C
            •  Voltage: 600V
            •  Temperature range: -40°C to +125°C
            •  Electrical protection: IP2XB






     HV Electrical Centers












     HV/LV Wiring Assemblies  20   Circuits  Part numbers, specifications, dimensions and performance data in this catalog are for general reference only and are subject to change
                                                           Female Connector
                                                                13848288
                 2

                                                                15530997
                 3

                     without notice. To verify product information, please contact a Delphi representative.
