High Voltage Auxiliary Modules
HV Auxiliary Modules HV Auxiliary Modules Shield-Pack HV280

™

2 Way Connection System with Multiple HVIL Options
HV Auxiliary Modules

HV Power Conversion

13737767

Chargers & Charging Cables

Application 13861584
• High voltage accessories connection system
Charging Inlets Description

• Sealed to device case
• Two HV power circuits (2.8 mm terminal)
• HVIL available in two configurations: pass-through header,
shunted in header
• HVIL with five-second time delay 13738743
• Finger proof/touch safe 2 2
Internal Battery Connections • Three keys/indexes
2
• Cable range: 2 mm to 5 mm power circuit; 0.5 mm
HVIL circuit

Performance
• Current capacity: 40A at 85°C
• Voltage: 600V
• Temperature range: -40°C to +125°C
• Sealing protection: IP67, IP6K9K
• Electrical protection: IP2XB
HV Electrical Centers

Header with Header with HVIL Mating Information
HV
HVIL
Key/ Shunted Pass-Through Mating Device Connector Connector
HVIL
HV/LV Wiring Assemblies 16 101 Part numbers, specifications, dimensions and performance data in this catalog are for general reference only and are subject to change
Index
to Module
Detail
13756860
13738743
13737767
13861584

13739582
13861585
102
13757523
13737768
13738744
13766241
13861586
13766024
103

13766022
without notice. To verify product information, please contact a Delphi representative.
