High Voltage Auxiliary Modules
HV Auxiliary Modules HV Auxiliary Modules HV150 On-Board Charger Connectors

3 Way Unshielded Connection System with HVIL
HV Auxiliary Modules

HV Power Conversion

13737769

Chargers & Charging Cables

Application 13861587
• High voltage unshielded system for on-board charger
Charging Inlets Description
applications (Level 1)

• Sealed connection system
• 1.5 mm terminal
• Unshielded with terminal spacing for HV applications
• Finger proof/touch safe
• Cable size: 2 mm
2
Internal Battery Connections Performance
• Two keys/indexes

• Current capacity: 16A at 85°C
• Voltage: 600V
• Temperature range: -40°C to +125°C
• Sealing protection: IP67, IP6K9K
• Electrical protection: IP2XB

HV Electrical Centers

HV/LV Wiring Assemblies 24 Key/ Part numbers, specifications, dimensions and performance data in this catalog are for general reference only and are subject to change

Mating Information
Mating Device Detail
Signal Connector
HV Connector
Header Connector
Index

101
13738743
13861587
13737769
13739582
13861588
13757521

102
13738744
without notice. To verify product information, please contact a Delphi representative.
