HV Auxiliary Modules HV Auxiliary Modules Shield-Pack HV280

™

PCB Mount or Pluggable Inner Connector
HV Auxiliary Modules

HV Power Conversion

13954070

Chargers & Charging Cables

Application 13954094
• High voltage accessories connection system
Charging Inlets Description

• Ideal for high corrosion environments with no exposed
fasteners on device case
• Sealed connection system
• Panel mount to device with face seal
• Internal HVIL (shunt in harness connector) 13824784
• Two options available
Internal Battery Connections • Two HV power circuits (2.8 mm terminal) 2
- Two-stage locking system for HVIL time delay
- Tooless mating system

• Flange size: 41 mm
• Finger proof/touch safe
2
2
• Cable range: 2 mm to 5 mm power circuit; 0.5 mm
HVIL circuit
• One key/index
Performance
• Current capacity: 40A at 85°C
HV Electrical Centers • Temperature range: -40°C to +125°C
• Voltage: 600V

• Sealing protection: IP67, IP6K9K
• Electrical protection: IP2XB
Availability
• Call for availability

HV/LV Wiring Assemblies 12 Key/ Part numbers, specifications, dimensions and performance data in this catalog are for general reference only and are subject to change

Mating Information

HV Connector
Mating Device
HV Connector
Header
PCB Inner
Detail
Index Connector Connector
(Tool required for disconnect)
(No tool required)
33107360
13824784
13954094
13954070
See print for information
101
without notice. To verify product information, please contact a Delphi representative.
