High Voltage Shielded/Sealed Connections
HV Auxiliary Modules RCS800 High Voltage

2 Way Connection System with HVIL
HV Auxiliary Modules

HV Power Conversion HV Power Conversion HV Power Conversion 83 53 83 53 13.5 13.5
68.5
68.5

F473110 69 74.3 74.3

Chargers & Charging Cables 48.8 48.8
69

Application F673110
• High voltage/high current modules: inverter, battery,
junction box, power electric box
Charging Inlets Description

• Bundle shielding with external braid
• Dual sealing connection system: mated and unmated header
• Panel mount to device with face seal to module
• Unique integrated electric interlock
- HVIL shunted in harness connector
Internal Battery Connections • ErgoMate™ Axial Mating Assist System on harness
• Two-stage disconnect for safe unmating

connector
• Two HV power circuits (8.0 mm round terminal)
• Flange size: 53 mm x 83 mm
• IP2XB Finger proof/touch safe
• Cable range: 35 to 50 mm power circuit; 0.5 to 0.75 mm
HVIL circuit
• Two keys/indexes 2 2
Performance
HV Electrical Centers • Voltage: 750V
• Current capacity: 230 A at 70°C

• Temperature range: -40°C to +125°C
• Sealing protection: IP67, IPX9K
• Electrical protection: IP2XB

Mating Information

HV/LV Wiring Assemblies 34 Key/ Part numbers, specifications, dimensions and performance data in this catalog are for general reference only and are subject to change

Index
Header Connector
HV Connector

F673110

F473110
1
2
F773110

F573110
without notice. To verify product information, please contact a Delphi representative.
