630-003
EMI/RFI Environmental Bulkhead Feed-Through
with Strain Relief
6
3
Front and Rear Panel Mount - 45° and 90°
630 A H 003 NF 16 2 H

Product Series Strain Relief Style (H, A, M, D)
Single Overall Fitting Type Fitting Style
EMI/RFI A = Rear Mount 1 = RFI/EMI Only
Shield Termination B = Front Mount 2 = RFI/EMI Environmental

Angle and Profile Cable Entry (Tables III and V)
H = 45∞
J = 90∞ Finish (Table II - See inside back
cover fold-out or page 14)
Basic Part No.

.910 (23.1) .125 (3.2) .710 (18.0)
.125 Max H Max Max F
D Mounting Hole (3.2) (Table Panel (Typ) (Table IV)
(4 Places) Max IV)
Panel
(Typ) J (Table IV)

K (Table IV)
G
(Table
A Thread IV)
Sym H (Table III)
C Sq. (Shown with
Rear Mount Type A
B Sq. RFI/EMI Environmental)

Sym J
(Shown With
Front Mount Type B
RFI/EMI Only)

E Dia.
Panel Cut-Out

STYLE H STYLE A STYLE M STYLE D
Heavy Duty Medium Duty Medium Duty Medium Duty
(Table V) (Table V) (Table V) (Table V)
L N N .135 (3.4)
Max

Cable M Cable P Cable Cable
Range Range Range P Range R
