390-036
Submersible EMI/RFI Cable Sealing Backshell
with Strain Relief
39
Type G - Rotatable Coupling - Low Profile

CONNECTOR 390 F S 036 M 16 10 M 6
DESIGNATORS Product Series Length: S only
A-F-H-L-S Connector (1/2 inch increments:
e.g. 6 = 3 inches)
ROTATABLE Designator
COUPLING Angle and Profile Strain Relief Style
(H, A, M, D)
A = 90°
TYPE G INDIVIDUAL B = 45° Cable Entry (Tables X, XI)
S = Straight
AND/OR OVERALL Shell Size (Table I)
SHIELD TERMINATION Basic Part No.
Finish (Table II)
.500 (12.7) Length ± .060 (1.52)
Max Minim Order
A Thread O-Rings Inch
(T I) (See Note 4)

C Typ.
(T I)

.88 (22.4) Max
E G
(Tab III) (Tab III)

(Tab III)

STYLE 2
(45° & 90°
See Note 1) H (Table III)

STYLE H STYLE A STYLE M STYLE D
Heavy Duty Medium Duty Medium Duty Medium Duty
(Table X) (Table XI) (Table XI) (Table XI)
T W X .135 (3.4)
Max

Cable V Cable Y Cable Y Cable
Range Range Range Entry Z
