High Current Sealed Connection Systems
HV Auxiliary Modules Power Pack 1000

2 Way Device and Pass-Through Connectors
HV Auxiliary Modules

HV Power Conversion HV Power Conversion HV Power Conversion

13849756

Chargers & Charging Cables

Application 13849758
• High current device applications
Charging Inlets Description
• Sealed pass-through panel mount system

• Sealed connection system
• Sealed panel mount prestages prior to fastening
• Panel mount secures in place through self tapping screws
• Pass-through connection accepts both straight and right 13959822
angle connectors
Internal Battery Connections • Cable range: 6 mm to 25 mm 2
• Silver-plated, multi-contact terminal system
2
• Two keys/indexes

Performance
• Current capacity: 145A at 85°C
• Voltage: 12V
• Temperature range: -40°C to +125°C
• Sealing protection: IP67, IP6K9K
Availability
HV Electrical Centers
• Call for pass-through availability

HV/LV Wiring Assemblies 46 Index Right Female Right Angle Female Straight Mating Information

Key/
Header
Index
13849758
13849756
13959822

13849757
Index Left

13849759
13959823
Part numbers, specifications, dimensions and performance data in this catalog are for general reference only and are subject to change
without notice. To verify product information, please contact a Delphi representative.
