Charging Inlets
HV Auxiliary Modules Combo 2 AC/DC Vehicle Charging Inlet

High Voltage/High Current Power Charging for IEC
HV Auxiliary Modules

76.4 7
76.4
HV Power Conversion Charge Inlet
98
7
98
Charge Inlet 141.9 141.9
IEC62196-3 Type II 119.5 IEC62196-3 Type II 119.5
Standard Sheet FF Standard Sheet FF

Chargers & Charging Cables

Application
239.9
• COMBO 2 charging interface for slow AC (Type II) and fast 95.1 25.7 98 239.9 95.1 25.7
Charging Inlets Charging Inlets Description 7 7
DC charging applications
98
• Interface complies with IEC62196

Charge Inlet
Charge Inlet • Combined charging system for electrical vehicle
IEC62196-3 Type II
IEC62196-3 Type II • AC/DC: slow + fast charge (600V, 125A)
Standard Sheet FF
Standard Sheet FF • Actuator pin for locking connector to inlet during charging
(with AC/DC Cap and Cord)
141.9
(with AC/DC Cap and Cord) • Optional thermistor for additional thermal protection during 119.5 141.9
Internal Battery Connections Performance
119.5
DC charging
• Wire Cross Section: Contact Pin/Present Pin (0.5 mm²),
PE (16 mm²), L1/N (6.0 mm²), DC+/-(40 mm²)
• Temperature range: -40°C to +80°C
• Voltage: 600V DC
• Max. current capacity: 32A AC/ 125A DC
• Sealing Protection: IP55 with cover, IP44 when mated 107.6 107.6
• Connector/Inlet mating and unmating force < 100N
• Number of mating cycles > 10,000
HV Electrical Centers Availability

• Call for availability

HV/LV Wiring Assemblies 64 Part numbers, specifications, dimensions and performance data in this catalog are for general reference only and are subject to change

without notice. To verify product information, please contact a Delphi representative.
