High Voltage Battery I/O Junction Block HV Auxiliary Modules

Custom 2 Way, 3 Way Bolted Connection HV Power Conversion
HV Auxiliary Modules

13658746 Chargers & Charging Cables
Application
• High voltage/unshielded bolted connections for battery I/O
Description
• Custom 2 Way and/or 3 Way high voltage Charging Inlets
• Fit to device case per customer requirements
• Ability to fasten direct to PCB
• Isolation between HV circuits through isolation towers
• Insert molded terminals and/or studs
Performance
• Continuous current: Per customer requirements
• Voltage: 600V
• Temperature range: -40°C to +125°C Internal Battery Connections

Internal Battery Connections

HV Electrical Centers

2 Way System 3 Way System
13658746 28115976 HV/LV Wiring Assemblies

Part numbers, specifications, dimensions and performance data in this catalog are for general reference only and are subject to change 69
without notice. To verify product information, please contact a Delphi representative.
