Combo 1 AC/DC Vehicle Charging Inlet HV Auxiliary Modules

High Voltage/High Current Power Charging for SAE
HV Auxiliary Modules

98 74.1 98 74.1
15.5 15.5
Charge Inlet Charge Inlet
IEC62196-3 Type I IEC62196-3 Type I 141.3 HV Power Conversion
141.3
Standard Sheet EE 119.5 Standard Sheet EE 119.5

Application Chargers & Charging Cables
232.4 93.1 232.4 93.1
• COMBO 1 charging interface for slow AC (Type I) and fast
98 34.5 98 34.5
DC charging applications
15.5 15.5
Description Charging Inlets
• Interface complies with SAE J1772 and IEC62196
• Combined charging system for electrical vehicle
Charging Inlets
Charge Inlet Charge Inlet • AC/DC: slow + fast charge (600V, 125A)
IEC62196-3 Type I IEC62196-3 Type I • Actuator pin for locking connector to inlet during charging
Standard Sheet EE Standard Sheet EE 141.3
141.3
(with AC/DC Cap and Cord) (with AC/DC Cap and Cord) • Optional thermistor for additional thermal protection
119.5 during DC charging
119.5
• Wire Cross Section: Contact Pin/Present Pin (0.5 mm²),
PE (16 mm²), L1/N (6.0 mm²), DC+/-(40 mm²)
Performance Internal Battery Connections
• Temperature range: -40°C to +80°C
• Voltage: 600V DC
• Max. current capacity: 32A AC/ 125A DC
• Sealing Protection: IP55 with cover, IP44 when mated
• Connector/Inlet mating and unmating force < 100N
• Number of mating cycles > 10,000

Availability
• Call for availability HV Electrical Centers
