Mode 3 Charging Cable Assemblies HV Auxiliary Modules

59.2
HV Auxiliary Modules
Infrastructure Drawings
59.2
105.5
210.1

105.5 HV Power Conversion
210.1

Type II – Rubber Overmold GB/T – Rubber Overmold

Type II – Plastic Handle Type III – Plastic Handle Chargers & Charging Cables
Chargers & Charging Cables
*Please reference page 55 for the vehicle interface drawings. Charging Inlets

Assembly Internal Battery Connections
Part Vehicle Infrastructure Picture Electrical Cable Certifications/
Number Interface Grip Interface Rating Cable Description Length (m/ft) Approvals

33401184 16A - 1-Phase, 240 VAC 3 - 2.5 mm + 1 - 0.75 mm IEC cable 6.0 m/15.7 ft CE
2
2
SAE J1772/ IEC62196 1
33403378 IEC62196 Plastic Type II 32A - 1-Phase, 240 VAC 3 - 6.0 mm² + 1 - 0.75 mm² IEC cable 6.0 m/15.7 ft CE

Type I

33401185 IEC62196 2 16A - 1-Phase, 240 VAC 3 - 2.5 mm + 1 - 0.5 mm IEC cable 6.0 m/15.7 ft CE HV Electrical Centers
2
2
Type III
Call for Rubber 3 16A - 3-Phase, 480 VAC 5 - 2.5 mm² + 1 - 0.75 mm² IEC cable 4.0 m/13.1 ft CE

availability overmold
IEC62196
33401404 IEC62196 Type II 32A - 3-Phase, 480 VAC 5 - 4.0 mm² + 1 - 0.75 mm² IEC cable 6.5 m/21.3 ft CE

Type II 4
33403734 32A - 3-Phase, 480 VAC 5 - 4.0 mm² + 1 - 0.75 mm² IEC cable 4.0 m/13.1 ft CE
Plastic

33401403 IEC62196 5 32A - 3-Phase, 480 VAC 5 - 4.0 mm² + 1 - 0.75 mm² IEC cable 6.5 m/21.3 ft CE
Type III
16A - 1-Phase, 250 VAC 3 - 2.5 mm² + 1 - 0.5 mm² IEC cable 5.0 m/16.4 ft N/A
Call for GB/T Rubber GB/T
availability overmold 6 HV/LV Wiring Assemblies
20234 20234 32A - 1-Phase, 250 VAC 3 - 6.0 mm² + 1 - 0.75 mm² IEC cable 5.0 m/16.4 ft N/A

Part numbers, specifications, dimensions and performance data in this catalog are for general reference only and are subject to change 57
without notice. To verify product information, please contact a Delphi representative.
