Chargers & Charging Cables
     HV Auxiliary Modules  Charge Coupler Connector Pigtails









  HV Auxiliary Modules


     HV Power Conversion












     Chargers & Charging Cables Chargers & Charging Cables  1  Type I – Rubber Overmold  2  Type I – Plastic Handle















     Charging Inlets










     Internal Battery Connections  3  Type II – Rubber Overmold  4  Type II – Plastic Handle








            Application
            •  Cable assemblies for integration into charging stations or
              portable cordsets per customer requirements

            Description
     HV Electrical Centers  •  Wiring crimps sealed from environment
            •  SAE J1772/IEC62196 Type I, IEC62196 Type II, and GB/T
              20234 compliant connections

            •  Rubber overmold and plastic grip options available

            Performance
            •  Current capacity: 15A to 32A
            •  Voltage range: 120V to 480V
            •  Temperature range: -40°C to +50°C               5 GB/T – Rubber Overmold
     HV/LV Wiring Assemblies  54  Part numbers, specifications, dimensions and performance data in this catalog are for general reference only and are subject to change
            •  Validation: See part number information








                     without notice. To verify product information, please contact a Delphi representative.
