Page 72 - Connecting today for a greener tomorrow

High Voltage Electrical Centers
HV Auxiliary Modules High Voltage Battery High Voltage Electrical

Center
Electrical Center
HV Auxiliary Modules

HV Power Conversion

Chargers & Charging Cables

Application
• High voltage battery electrical center
Charging Inlets Description

• Battery pack mounted contactor and sensing device
• Provides galvanic isolation of the high voltage battery
• Pre-charge protects contactors from high current
in-rush
• Sensing of battery current and voltage
• Provides circuit protection for auxiliary loads Application
Internal Battery Connections • High voltage electrical center
• Size: 268 mm L x 200 mm W x 78 mm H

Description
• Custom solutions to system requirements
• Integration of terminal, contactor, and/or HV fuses
• Shielded and sealed system
• Harness connections through Shield-Pack™
connection systems
• Venting for pressure variations
HV Electrical Centers HV Electrical Centers

HV/LV Wiring Assemblies 72 Part numbers, specifications, dimensions and performance data in this catalog are for general reference only and are subject to change

without notice. To verify product information, please contact a Delphi representative.
